Dalla GIF originale monocromatica realizzata dall' HST ho applicato una elaborazione con l'ausilio della " palette" che permette di creare una mappatura a colori ed evidenziare le varie fasi di frammentazione della cometa 73/P S-W.

From the monochrome original GIF realized by the HST I have applied an elaboration with the aid of the " palette" that it allows to create a color map and to underline the various phases of fragmentation of the comet 73/P S-W.

Comet
73/P
Schwassmann
Wachmann
In questa GIF animata realizzata il 18 aprile 2006 dal telescopio spaziale Hubble ( HST ) viene immortalato il disgregarsi del frammento B della cometa 73P/Schwassmann- Wachmann.

 In this GIF animated realized April 18 th 2006 from the spatial telescope Hubble (HST) the is immortalized to break up him some fragment B of the comet 73P/Schwassmann - Wachmann.

photo credit: NASA -  original image HST  GIF 223 KB
Elaborazione con applicata la funzione negativa inversa in cui risaltano i numerosi frammenti di varie dimensioni.


Elaboration with applied the inverse negative function in which are underlined the numerous fragments of various dimensions.

Elaboration image: Davide Romanini  GIF 129 KB

A mio avviso questa elaborazione è la più completa perchè vengono evidenziate le reazioni morfologiche e fisiche conseguenti all'evento di frammentazione della 73/P S-W.

To my notice this elaboration is the most complete because the morphological reactions and consequent physics to the event of fragmentation of the 73/P S-W are underlined.
Elaboration image: Davide Romanini GIF 153 KB
Stesse note di cui sopra citate.


It was notes of which above you quote.

Elaboration image: Davide Romanini GIF 293 KB

 Technical data of acquisition
 CCD Acquisition:  SBIG ST7 XME 402E with self guiding
 Temperature of exercise -20°C
  Optic configuration of the telescope:
 Refractor Skywatcher 120-900 mm. ED PRO + focal reducer Meade f6,3
 ( focal equivalent and inclusive draught 630 mm.)
 frammed field 42 x 28 arc minutes
 German Equatorial Mount:
 Gemini G 41 Observatory Plus and FS 2 system control
 Luminance integration time:
 Total integration from 34' ( 60"x34 frame )
 with  filter Astronomik CLS Profi
 Software used for the acquisition and the elaboration:
 CCDSoft, Astroart, Ulead Gif Animator
 Date of acquisition: 24/04/2006
 times give to her times 22:00 22:35 local time
 Zone of acquisition:
 Fixed posting of San Giuliano P.no ( Piacenza ) Italy
 LAT.45° 04' 05"N - LONG. 10° 00' 00"E
 Author Astroimager:
 Davide Romanini - ASTRODAVID -


 Basic objet information
 Discovery: 2 May 1930
 Discoverer: Arnold Schwassmann - Arno Arthur Wachmann, observatory in Hamburg ( Germany )
 Information for 24 apr 2006 22.00.44
 (Julian day number 2453850.35815)
 Name: 73P Schwassmann-Wachmann
 Magnitude: 8.9
 Elongation: 131.1°
 Distance: 0.1714 AU (25.6 million km)
 Radius vector: 1.1261 AU (168.5 million km)
 Horizontal parallax: 51.30"
 Topocentric coordinates
 Apparent coordinates for the epoch of date:
 Right ascension: 15h 53m 22.6s
 Declination: +28° 49' 23"
 Constellation: Corona Borealis


      GIF 1,6 MB
